  Acro S-430

SPECIFICATION
ITEM / TYPE
S-320
S-430
S-500
S-540
S-650
S-1060
Work table dimension mm
600x300
5H x 2P
5H x 2P
5H x 2P
5H x 2P
5H x 2P
Table travel (x axis) mm
300
1HP x AC
1HP x AC
1HP x AC
1HP x AC
1HP x AC
Table travel (y axis) mm
200
5HP x 6P
5HP x 6P
5HP x 6P
5HP x 6P
5HP x 6P
Quill travel (Z1 axis) mm
200/200
2-25mm
2-25mm
2-25mm
2-25mm
2-25mm
Work head travel (Z axis) mm
420
450
560
600
960
800
Net weight kg
950 kgs
1350 kgs
2350 kgs
1850 kgs
3500 kgs
4300 kgs
Machine dimensions (LxWxH) mm
1200 x 950 x 2000
1450 x 1150 x 2000
1300 x 1200 x 2210
1600 x 1800 x 2250
2000 x 2060 x 2550
1700 x 2700 x 2700
Work tank dimension mm
870 x 520 x 320
1100 x 600 x 400
770 x 850 x 380
1250 x 700 x 500
1250 x 900 x 525
1500 x 1000 x 700
Fluid reservoir dimensions (LxWxH) mm
Built in
1000 x 950 x 460
Built in
1400 x 900 x 500
1970 x 1400 x 1060
1300 x 2200 x 500
Oil tank Capacity L
300L
400L
580L
650L
800L
1850L




  OPCH

OPCH - Series High-Speed C Frame Hydraulic Press
Item / Model
Capacity
Stroke
Power
Ram
Dayligh
Fast Down Speed
Pressing Speed
Return Speed
OPCH-5
5 Tons
250 mm
3 HP
71 mm
400 mm
14.0/11.6 M/Min
3.5/2.9 M/Min
16.5/13.7 M/Min
OPCH-10
10 Tons
300 mm
5 HP
85 mm
450 mm
14.0/11.6 M/Min
2.2/1.8 M/Min
8.0/6.6 M/Min
OPCH-15
15 Tons
400 mm
5 HP
100 mm
550 mm
14.0/11.6 M/Min
1.9/1.5 M/Min
5.2/4.3 M/Min
OPCH-20
20 Tons
400 mm
7.5 HP
100 mm
550 mm
14.0/11.6 M/Min
1.9/1.5 M/Min
5.2/4.3 M/Min
OPCH-30
30 Tons
400 mm
7.5 HP
136 mm
550 mm
14.0/11.6 M/Min
1.3/1.0 M/Min
7.3/6.0 M/Min
OPCH-40
40 Tons
400 mm
7.5 HP
165 mm
550 mm
11.6/9.6 M/Min
0.9/0.7 M/Min
5.7/4.7 M/Min
OPCH-50
50 Tons
400 mm
7.5 HP
180 mm
550 mm
11.6/9.6 M/Min
0.7/0.5 M/Min
3.9/3.2 M/Min
OPCH-60
60 Tons
400 mm
7.5 HP
200 mm
550 mm
11.6/9.6 M/Min
0.6/0.5 M/Min
2.9/2.4 M/Min




  HCP HIGH SPEED FORGING PRESSES

SPECIFICATIONS
MODEL / ITEM
UNITY
HCP-200
HCP-300
HCP-400
HCP-500
HCP-600
Capacity
Tons
200
300
400
500
600
Stroke of ram
mm
150
150
150
150
250
Adjustment of ram
mm
60
60
60
60
60
Number of stroke
spm
100
95
90
85
80
Work number of stroke
spm
18
18
18
16
16
shut height
mm
440
430
480
510
900
rated taonnage point
mm
5
5
5
5
5
(L-R & F-B) Ram dimension
mm
495X400
565X445
655X505
675X605
675X605
(L-R & F-B) Table dimension
mm
630X800
680X860
750X920
770X1100
770X1100
Main Motor
KW/HPxP
18.5KWx6P
25HPx6P
30KWx6P
40HPx6P
37KWx6P
50HPx6P
37KWx6P
50HPx6P
45KWx6P
60HPx6p
Motor of Lubricating
0.1 x 4P
0.1 x 4P
0.1 x 4P
0.1 x 4P
0.1 x 4P
0.1 x 4P
Ejector in the ram
10 x 20
10 x 20
10 x 20
10 x 20
10 x 20
10 x 20
Ejector in the table
10 x 40
10 x 40
10 x 40
10 x 40
10 x 40
10 x 40
Air pressure
5
5
5
5
5
5
Press weight
Kg
16500
20500
25500
32000
35000
(LXwXH) press dimension
mm
1960x2340x3280
2010x2470x3560
2210x2670x3770
2410x2860x3990
2760x2700x4700
